Redleaf solar panel for RD3019 Pro

• Solar panel compatible with the Redleaf RD3019 Pro trail camera
• Built-in lithium-ion battery charged by solar energy
• Significantly extends the camera's battery life thanks to external power supply
• Battery pre-charging via USB port
• Sturdy mounting bracket with adjustable angle for optimal sun exposure
• Automatic power switching to batteries or rechargeable batteries installed in the camera when the panel battery is discharged
• Operating temperature range: -20ºC to 80ºC
• Lightweight, compact design allows for easy transport and installation
• Solar panel: convenience, savings, and eco-friendliness

The solar panel for the Redleaf RD3019 Pro trail camera is the perfect solution for trail camera users who want to extend their device's operating time. It features a lithium-ion battery with a capacity of up to 4500 mAh. This configuration significantly extends the camera's lifespan, reducing the need for frequent battery replacement and, consequently, reducing the costs associated with charging or purchasing batteries.

Long Camera Operation Time
After connection, the camera will primarily use the energy stored in the solar panel's lithium-ion battery. When its charge level drops below the minimum, the device automatically switches to AA or NiMH batteries. This allows you to enjoy longer, maintenance-free operation, which is especially important during long-term monitoring of hard-to-reach areas.

USB Pre-Charging Function
One of the panel's unique features is the ability to pre-charge the battery using the included USB cable. This allows the device to operate almost immediately after installation, without having to wait for a full solar charge. This is especially useful when you need to immediately activate your new panel after dark or on a cloudy day.

Easy and Convenient Installation
The Redleaf RD3019 Pro camera trap solar panel comes with a sturdy mount that ensures secure mounting to a tree or wall. An adjustable joint allows you to precisely align the solar cells with the sun, ensuring maximum charging efficiency. This intuitive solution allows for quick and reliable field setup, without the need for advanced tools.

Quality and Durability
The Redleaf RD3019 Pro camera trap solar panel is designed for a variety of use scenarios. Its rugged construction and resistance to external factors make it ideal for outdoor use. The panel can operate in temperatures ranging from -20ºC to as high as 80ºC. Whether you're monitoring wildlife or securing your property, you can count on the device's reliability and long-lasting operation.

Charge Level Indicator
The Redleaf RD3019 Pro camera trap solar panel features a clear, four-LED charge level indicator. This allows you to easily assess the battery's charge level. Each LED represents 25% charge. The clear and intuitive indicators are useful both around the house and in the field. Specifications

• Solar panel for Redleaf RD3019 Pro
• Output Voltage and Current: 6 V / 2 A or 12 V / 1 A
• Battery Capacity: 4500 mAh (3.7 V)
• Output Interface: DC Jack
• USB Charging Port: Micro USB (5 V / 1 A)
• Power Indicators: 4 LEDs
• Solar Charging Current: Approx. 200 mA
• Charging Time: Up to 4 Hours
• Operating Temperature: -20 – 80ºC

Dimensions

• Solar Panel: 120 × 65 mm
• Total: 153 × 85 × 26 mm
• Weight: 178 g

Kit Contents

• Solar Panel
• DC Cable
• microUSB – USB-A Cable
• Wall Mount
